Product Description
The Adafruit KB2040 (Kee Boar) is a compact, high-performance RP2040-based development board designed specifically for mechanical keyboard (keeb) builds. With the same size and near-identical pinout as the classic Arduino Pro Micro, KB2040 makes upgrading to a modern microcontroller effortless—no adapter plates required.
Powered by the RP2040 dual-core ARM Cortex-M0+ processor, the KB2040 delivers excellent performance for keyboard scanning, RGB lighting, macros, and custom firmware. It is fully compatible with CircuitPython, MicroPython, and QMK, making it a favorite choice for both beginners and advanced keyboard builders in Egypt.
This board combines the best features from popular keeb controllers: castellated pads, USB Type-C, STEMMA QT / Qwiic connector, 8MB QSPI Flash, and an onboard NeoPixel LED. With 20 usable GPIO pins, it can easily handle large key matrices such as 65% layouts (5×15) or up to 100 keys.
Designed on a compact 2-layer PCB, the KB2040 is ideal for space-constrained keyboard cases. The RAW power output and optional fuse bypass allow high-current RGB LED setups, while the Boot button doubles as a programmable input for custom functionality.
Whether you’re building your first custom keyboard or a high-end RGB mechanical keeb, the Adafruit KB2040 offers a powerful, flexible, and modern solution.
Key Features
- RP2040 dual-core ARM Cortex-M0+ @ up to 133 MHz
- Pro Micro–compatible form factor and pinout
- 8MB QSPI Flash for CircuitPython / MicroPython
- 20 GPIO pins (18 castellated + 2 via STEMMA QT)
- Supports large keyboard matrices (up to 100 keys)
- USB Type-C with native USB bootloader
- STEMMA QT / Qwiic connector for I2C or extra GPIO
- Onboard NeoPixel RGB LED
- Reset button + Bootloader button (usable as GPIO)
- RAW power output with optional fuse bypass (up to 2A)
- Compact size: 35.0 × 17.8 mm
RP2040 Chip Highlights
- Dual ARM Cortex-M0+ cores
- 264KB SRAM
- Up to 16MB external Flash support
- 2× UART, 2× SPI, 2× I2C
- 16 PWM channels
- USB 1.1 host & device support
- 8 PIO state machines
Ideal Applications
- Custom mechanical keyboards (QMK / CircuitPython)
- RGB keyboard builds
- DIY macro pads and keypads
- HID devices (keyboard, mouse, MIDI)
- Embedded USB projects
